ZKTeco ZKBio830 All-in-One Biometric Smart POS Terminal Intel Core i3-4010U, 4GB 128GB SSD, 15 Inch Bezel Free Capacitive Touch Screen

Power-efficient Intel? Celeron J1900 2.0 GHz Quad-Core processor

? 15? Bezel-free true-flat display with PCAP touch

? Slim stand design with small footprint

? Multiple I/O interfaces for peripherals

? Optional built in 1D/2D barcode scanner, MSR, RFID

? Optional VFD&10”customer display

? Faster installation and maintainability

SKU: BPOS0098 Categories: POS Machines, POS Supplies & Accessories Tag: ZKBio 830

Brand	ZKTeco
Model Number	ZKBio 830

Model NameZKBio810
ZKBio830
ZKBio850
SYSTEM
CPUZKBio810：Intel Celeron J1900 @ 1.99GHz
ZKBio830：Intel Core i3-4030U @ 1.70GHz
ZKBio850：Intel Core i5-4210U @ 1.70GHz
ProcessorZKBio810 : Intel® Celeron® J1900 Quad-Core Processor (2.0 GHz)
ZKBio830 : Intel® Core™ i3-4005U Pro-cessor(1.7GHz) Intel® Core™ i3-4010U Pro-cessor(1.7GHz)
ZKBio850 : Intel® Core™ i5-4200U Processor (1.6 GHz up to 2.6 GHz) Intel® Core™ i5-4210U Processor (1.7 GHz up to 2.7 GHz)
System Memory2GB Standard, DDR3L 1666MHz (Max.8GB)
Storage Device32GB Msata SSD Standard,1*2.5’’ HDD / 2.5’’ SSD
OS SupportedWindows 7,Windows 8, Windows 10 IoT Enterprise, POS Ready 7,Linux
AudioRealtek ALC662
DISPLAY AND TOUCH
Types15” TFT LCD, LED Backlight
Resolution1024*768
Touch ScreenProjected Capacitive
Customer DisplayLED 8C digital tube
EXTERNAL I/O PORTS
VGA1*DB-15
USBZKBio810：5*USB 2.0 & 1*USB3.0
ZKBio830：2*USB2.0 & 4*USB3.0
ZKBio850：2*USB2.0&4*USB3.0
COMZKBio810：3
ZKBio830：3
ZKBio850：3
LAN1
Audio1*Line-out
Cash Drawer1
0
0
HDMI1
PHYSICAL ENVIRONMENTAL
Operating Temperature0℃ ~ 35℃ at 20%-80% Humidity
Storage Temperature- 20℃ ~ 55℃ at 20%-80% Humidity
Dimensions (L*W*H)347*372*402mm
Packing Dimensions450*420*480mm
Net Weight6.10kg
Packing Weight8.21kg
Power SupplyAdaptor 12V DC 5A
CertificationsCE, FCC
OPTIONS & PERIPHERALS
Second Display10”TFT LCD
Customer Display (VFD)VFD(2*20 lines)
MSR3 Tracks
Fingerprint ReaderBuilt-in fingerprint reader
Power SupplyCE FCC

Printer Combo
